Actuator with micro-switch
126m
Actuator with 4 cables for underfloor heating systems manifolds and thermostatic valves, with micro-switch for direct operation on pumps, fan-coil, etc.
Motion: rotation
Working temperature: 0 – 100°C
Operating power: 1W
Opening/closing time: 3-4 min.
Cable lenght: 1m
Protection: IP54
Normally closed
| Code | Size 1 | Size 2 | Version | M | F | ||
|---|---|---|---|---|---|---|---|
| 0012631230 | Ø 26x1,5 | 230V | 1 | 10 | |||
| 0012641230 | Ø 30x1,5 | 230V | 1 | 10 |
M = Handle color - F = Finishing color
